1.Permohonan:
Kabel ini bertujuan untuk sistem kuasa, cahaya dan kawalan kapal, platform petrol dan bangunan luar pesisir, dan ia juga tersedia untuk industri metalurgi, kerja kimia, loji kuasa dan lombong dll.
2.Piawaian:
IEC 60092-350,IEC 60092-353,IEC 60332-3-22,IEC 60754,IEC 61034
3.Pembinaan Kabel:
|
Konduktor: Kuprum tin atau biasa, terkandas kelas2 IEC 60228 Penebat: XLPE / EPR Pengisi: Penutup dalam Perisai: Jalinan dawai tembaga tin atau biasa/Jalinan dawai keluli Sarung luar: EPR/LSZH |
|
4.Parameter :
|
Bilangan teras×luas keratan rentas nominal (mm²) |
CJPF/SC CJPJ/SC CJV/DA, SA |
CJ86/SC CJ85/SC CJ82/DA, SA |
CJPF86/SC CJPJ85/SC CJV82/DA,SA CJPF96/SC CJPJ95/SC CJV92/DA,SA |
|||||||
|
Diameter yang dikira (mm) |
Jisim yang dikira (kg/km) |
Diameter yang dikira (mm) |
Jisim yang dikira (kg/km) |
Diameter yang dikira (mm) |
Jisim yang dikira (kg/km) |
|||||
|
nom. |
maks. |
nom. |
maks. |
nom. |
maks. |
CJPF86 CJPJ85 |
CJPF96 CJPJ95 |
|||
|
1*1 |
5.2 |
6.0 |
35 |
6.2 |
7.2 |
58 |
7.8 |
8.8 |
88 |
85 |
|
1*1.5 |
5.5 |
6.4 |
41 |
6.5 |
7.4 |
66 |
8.1 |
9.2 |
97 |
94 |
|
1*2.5 |
5.9 |
6.8 |
53 |
6.9 |
7.8 |
80 |
8.5 |
9.6 |
113 |
109 |
|
1*4 |
6.5 |
7.4 |
72 |
7.5 |
8.4 |
101 |
9.1 |
10.5 |
136 |
132 |
|
1*6 |
7.1 |
8.0 |
94 |
8.1 |
9.2 |
127 |
9.7 |
11.0 |
164 |
159 |
|
1*10 |
8.0 |
9.0 |
137 |
9.2 |
10.5 |
178 |
10.6 |
12.0 |
215 |
209 |
|
1*16 |
9.2 |
10.5 |
202 |
10.2 |
11.5 |
245 |
11.8 |
13.0 |
290 |
284 |
|
1*25 |
10.9 |
12.0 |
301 |
12.1 |
13.5 |
358 |
13.7 |
15.0 |
410 |
403 |
|
1*35 |
12.4 |
14.0 |
408 |
13.4 |
15.0 |
467 |
15.7 |
17.0 |
567 |
554 |
|
1*50 |
13.8 |
15.5 |
559 |
15.5 |
17.0 |
666 |
17.3 |
19.0 |
741 |
727 |
|
1*70 |
16.0 |
17.5 |
768 |
17.5 |
19.0 |
884 |
19.5 |
21.0 |
977 |
961 |
|
1*95 |
17.9 |
19.5 |
1012 |
19.6 |
21.5 |
1152 |
21.4 |
23.0 |
1244 |
1227 |
|
1*120 |
19.9 |
21.5 |
1269 |
21.6 |
23.5 |
1424 |
23.6 |
25.5 |
1535 |
1516 |
|
1*150 |
22.1 |
24.0 |
1581 |
23.6 |
25.5 |
1742 |
25.8 |
28.0 |
1875 |
1853 |
|
1*185 |
24.5 |
26.5 |
1944 |
26.0 |
28.0 |
2123 |
28.4 |
30.5 |
2281 |
2257 |
|
1*240 |
27.6 |
29.5 |
2496 |
29.1 |
31.5 |
2698 |
31.7 |
34.0 |
2281 |
2860 |
|
1*300 |
30.2 |
32.5 |
3079 |
31.9 |
34.5 |
3315 |
34.3 |
37.0 |
3505 |
3476 |
|
1*400 |
33.9 |
36.5 |
4072 |
35.4 |
38.0 |
4321 |
38.7 |
41.5 |
4658 |
4614 |
|
2*1 |
7.9 |
9.0 |
63 |
9.1 |
10.5 |
103 |
10.5 |
12.0 |
139 |
134 |
|
2*1.5 |
8.5 |
9.6 |
76 |
9.7 |
11.0 |
120 |
11.1 |
12.5 |
158 |
152 |
|
2*2.5 |
9.5 |
10.5 |
104 |
10.5 |
12.0 |
149 |
12.3 |
13.5 |
200 |
194 |
|
2*4 |
10.7 |
12.0 |
141 |
11.9 |
13.5 |
197 |
13.5 |
15.0 |
248 |
241 |
|
2*6 |
12.1 |
13.5 |
192 |
13.1 |
14.5 |
249 |
15.4 |
17.0 |
347 |
335 |
|
2*10 |
13.9 |
15.5 |
279 |
15.6 |
17.0 |
387 |
17.4 |
19.0 |
463 |
449 |
|
2*16 |
16.1 |
17.5 |
411 |
17.6 |
19.0 |
528 |
19.6 |
21.5 |
621 |
605 |
|
2*25 |
19.7 |
21.5 |
620 |
21.4 |
23.0 |
774 |
23.4 |
25.5 |
884 |
865 |
|
2*35 |
22.5 |
24.5 |
836 |
24.2 |
26.0 |
1011 |
26.2 |
28.5 |
1135 |
1113 |
|
2*50 |
25.5 |
27.5 |
1152 |
27.2 |
29.5 |
1351 |
29.4 |
31.5 |
1502 |
1477 |
|
2*70 |
29.7 |
32.0 |
1577 |
31.4 |
33.5 |
1809 |
33.8 |
36.5 |
1996 |
1967 |
|
2*95 |
33.9 |
36.5 |
2102 |
35.4 |
38.0 |
2351 |
38.7 |
41.5 |
2688 |
2644 |
|
2*120 |
37.7 |
40.5 |
2624 |
39.4 |
42.0 |
2918 |
42.7 |
45.5 |
3290 |
3242 |
|
3*1 |
8.3 |
9.4 |
78 |
9.5 |
11.0 |
121 |
10.9 |
12.0 |
159 |
153 |
|
3*1.5 |
9.2 |
10.5 |
101 |
10.2 |
11.5 |
144 |
11.8 |
13.0 |
189 |
183 |
|
3*2.5 |
10.1 |
11.5 |
136 |
11.1 |
12.5 |
183 |
12.9 |
14.0 |
237 |
230 |
|
3*4 |
11.4 |
12.5 |
188 |
12.6 |
14.0 |
247 |
14.7 |
16.0 |
334 |
323 |
|
3*6 |
12.8 |
14.0 |
259 |
13.8 |
15.5 |
320 |
16.1 |
17.5 |
423 |
410 |
|
3*10 |
14.8 |
16.5 |
385 |
16.5 |
18.0 |
500 |
18.3 |
20.0 |
580 |
565 |
|
3*16 |
17.2 |
19.0 |
575 |
18.9 |
20.5 |
708 |
20.7 |
22.5 |
798 |
781 |
|
3*25 |
21.2 |
23.0 |
885 |
22.7 |
24.5 |
1040 |
24.9 |
27.0 |
1168 |
1147 |
|
3*35 |
24.2 |
26.0 |
1198 |
25.7 |
28.0 |
1375 |
28.1 |
30.5 |
1531 |
1507 |
|
3*50 |
27.5 |
29.5 |
1660 |
29.0 |
31.0 |
1861 |
31.6 |
34.0 |
2049 |
2022 |
|
3*70 |
32.0 |
34.5 |
2280 |
33.7 |
36.0 |
2529 |
36.3 |
39.0 |
2745 |
2714 |
|
3*95 |
36.5 |
39.0 |
3043 |
38.0 |
40.5 |
3311 |
41.5 |
44.5 |
3689 |
3642 |
|
3*120 |
40.6 |
43.5 |
3806 |
42.8 |
45.5 |
4225 |
45.8 |
49.0 |
4541 |
4489 |
|
3*150 |
45.3 |
48.5 |
4754 |
47.3 |
50.5 |
5200 |
50.7 |
54.0 |
5593 |
5534 |
|
3*185 |
50.2 |
53.5 |
5837 |
52.4 |
56.0 |
6356 |
55.8 |
59.5 |
6788 |
6724 |
|
4*1 |
9.2 |
10.5 |
100 |
10.2 |
11.5 |
143 |
11.8 |
13.0 |
188 |
182 |
|
4*1.5 |
10.0 |
11.0 |
124 |
11.0 |
12.5 |
171 |
12.8 |
14.0 |
225 |
218 |
|
4*2.5 |
10.9 |
12.0 |
170 |
12.1 |
13.5 |
227 |
14.2 |
15.5 |
311 |
300 |
|
4*4 |
12.6 |
14.0 |
243 |
13.6 |
15.0 |
302 |
15.9 |
17.5 |
404 |
391 |
|
4*6 |
14.0 |
15.5 |
329 |
15.7 |
17.5 |
438 |
17.5 |
19.0 |
515 |
501 |
|
4*10 |
16.4 |
18.0 |
502 |
18.1 |
20.0 |
630 |
19.9 |
21.5 |
716 |
700 |
|
4*16 |
19.0 |
20.5 |
751 |
20.5 |
22.5 |
890 |
22.7 |
24.5 |
1007 |
989 |
|
4*25 |
23.4 |
25.5 |
1147 |
25.1 |
27.0 |
1329 |
27.3 |
29.5 |
1469 |
1446 |
|
4*35 |
26.7 |
29.0 |
1557 |
28.4 |
30.5 |
1766 |
30.6 |
33.0 |
1923 |
1897 |
|
4*50 |
30.5 |
33.0 |
2179 |
32.0 |
34.5 |
2402 |
34.6 |
37.0 |
2608 |
2579 |
|
5*1 |
10.0 |
11.5 |
117 |
11.0 |
12.5 |
164 |
12.8 |
14.0 |
218 |
211 |
|
7*1 |
10.8 |
12.0 |
149 |
12.0 |
13.5 |
205 |
14.1 |
15.5 |
289 |
278 |
|
10*1 |
13.7 |
15.0 |
211 |
15.4 |
17.0 |
317 |
17.2 |
19.0 |
392 |
379 |
|
12*1 |
14.1 |
15.5 |
241 |
15.8 |
17.5 |
351 |
17.6 |
19.5 |
427 |
413 |
|
14*1 |
15.0 |
16.5 |
278 |
16.5 |
18.0 |
387 |
18.5 |
20.0 |
476 |
461 |
|
16*1 |
15.8 |
17.5 |
311 |
17.3 |
19.0 |
425 |
19.3 |
21.0 |
517 |
502 |
|
19*1 |
16.6 |
18.0 |
356 |
18.3 |
20.0 |
485 |
20.1 |
22.0 |
573 |
557 |
|
24*1 |
19.5 |
21.0 |
450 |
21.2 |
23.0 |
602 |
23.2 |
25.0 |
712 |
693 |
|
27*1 |
19.9 |
21.5 |
494 |
21.6 |
23.5 |
649 |
23.6 |
25.5 |
760 |
741 |
|
30*1 |
20.8 |
22.5 |
548 |
22.3 |
24.0 |
700 |
24.5 |
26.5 |
826 |
806 |
|
33*1 |
21.6 |
23.5 |
595 |
23.1 |
25.0 |
752 |
25.3 |
27.5 |
882 |
861 |
|
37*1 |
22.4 |
24.5 |
655 |
24.1 |
26.0 |
829 |
26.3 |
28.5 |
964 |
942 |
|
5*1.5 |
10.8 |
12.0 |
148 |
12.0 |
13.5 |
204 |
14.1 |
15.5 |
288 |
277 |
|
7*1.5 |
11.9 |
13.5 |
196 |
12.9 |
14.5 |
252 |
15.2 |
16.5 |
349 |
337 |
|
10*1.5 |
15.1 |
16.5 |
277 |
16.6 |
18.0 |
386 |
18.6 |
20.5 |
475 |
460 |
|
12*1.5 |
15.6 |
17.0 |
317 |
17.1 |
18.5 |
431 |
19.1 |
21.0 |
521 |
506 |
|
14*1.5 |
16.3 |
18.0 |
360 |
18.0 |
19.5 |
486 |
19.8 |
21.5 |
573 |
557 |
|
16*1.5 |
17.2 |
19.0 |
403 |
18.9 |
20.5 |
537 |
20.7 |
22.5 |
626 |
610 |
|
19*1.5 |
18.3 |
20.5 |
473 |
19.8 |
21.5 |
606 |
22.0 |
24.0 |
719 |
701 |
|
24*1.5 |
21.5 |
23.5 |
597 |
23.0 |
25.0 |
754 |
25.2 |
27.0 |
883 |
862 |
|
27*1.5 |
22.0 |
24.0 |
656 |
23.7 |
25.5 |
827 |
25.9 |
28.0 |
960 |
938 |
|
30*1.5 |
22.7 |
24.5 |
718 |
24.4 |
26.5 |
895 |
26.6 |
28.5 |
1032 |
1010 |
|
33*1.5 |
23.8 |
26.0 |
791 |
25.3 |
27.5 |
965 |
27.7 |
30.0 |
1119 |
1095 |
|
37*1.5 |
24.7 |
26.5 |
873 |
26.4 |
28.5 |
1065 |
28.6 |
31.0 |
1212 |
1188 |
|
5*2.5 |
12.1 |
13.5 |
209 |
13.1 |
14.5 |
266 |
15.4 |
17.0 |
364 |
352 |
|
7*2.5 |
13.1 |
14.5 |
272 |
14.1 |
15.5 |
335 |
16.4 |
18.0 |
439 |
426 |
|
10*2.5 |
16.7 |
18.5 |
386 |
18.4 |
20.0 |
516 |
20.2 |
22.0 |
604 |
588 |
|
12*2.5 |
17.3 |
19.0 |
447 |
19.0 |
20.5 |
581 |
20.8 |
22.5 |
671 |
654 |
|
14*2.5 |
18.3 |
20.0 |
518 |
19.8 |
21.5 |
651 |
22.0 |
24.0 |
765 |
747 |
|
16*2.5 |
19.3 |
21.0 |
582 |
21.0 |
23.0 |
732 |
23.0 |
25.0 |
841 |
822 |
|
19*2.5 |
20.5 |
22.5 |
684 |
22.0 |
24.0 |
833 |
24.2 |
26.0 |
958 |
938 |
|
24*2.5 |
24.1 |
26.0 |
863 |
25.6 |
27.5 |
1039 |
28.0 |
30.0 |
1194 |
171 |
|
27*2.5 |
24.6 |
26.5 |
953 |
26.3 |
28.5 |
1144 |
28.5 |
30.5 |
1291 |
1267 |
|
30*2.5 |
25.5 |
27.5 |
1045 |
27.2 |
29.5 |
1244 |
29.4 |
31.5 |
1395 |
1370 |
|
33*2.5 |
26.7 |
29.0 |
1151 |
28.2 |
30.5 |
1346 |
30.8 |
33.0 |
1529 |
1503 |
|
37*2.5 |
27.7 |
30.0 |
1273 |
29.4 |
31.5 |
1489 |
31.8 |
34.0 |
1666 |
1639 |
5. Kemajuan Pengeluaran
6. Sijil:
 |
 |
7. pembungkusan:
-Gendang kayu keluli (pengasapan)
Panjang kabel dalam setiap dram: 1000m/2000m atau mengikut keperluan panjang kabel sebenar.
-Saiz gendang:
Mengikut panjang kabel dan saiz bekas
Untuk memetik harga yang tepat kepada anda, sila beritahu kami kuantiti panjang kabel yang anda perlukan. Kuantiti yang lebih besar, lebih banyak faedah diskaun sedia untuk anda!
-Pelabuhan Penghantaran:
Qingdao, atau pelabuhan lain mengikut keperluan anda.
-Pengangkutan laut:
Sebut harga FOB/C&F/CIF semuanya tersedia.
Cool tags: kabel marin, pengeluar kabel marin China, pembekal, kilang
